26 Chapter 2, Cutter Controls
Force settings are shown by one LED for the first range and combinations
of LEDs for the second and third ranges. Since the actual numbers are not
on the control panel, consult these tables to find the numerical equivalent
of the LEDs shown.
First Range (15 - 100 grams)
Force settings in the first range are indicated by one blinking LED to
indicate the cutting force. The example below shows 80 grams.
15 20 30 40 50 60 70 80 90 100
Second Range (110 - 190 grams)
Force settings are indicated by blinking of the
last
LED of the LED bar in
combination with one of the other LEDs. The example below shows a
setting of 150 grams.
110 120 130 140 150 160 170 180 190
Third Range (200 - 500 grams)
Force settings are indicated by blinking of the
first four
LEDs of the LED
bar in combination with other LEDs in 50-gram increments.
Example showing a 200-gram setting.
200 200 200 200 250 300 350 400 - -
Example showing a 250-gram setting.
200 200 200 200 250 300 350 400 - -
Example showing a 400-gram setting.
200 200 200 200 250 300 350 400 450 500
All available values are shown in the tables at the end of this chapter.
When TOOL-UP is selected, the force adjustment refers to the force
that will be used for the automatic sheet-off.
