Chapter 5, Cutter Maintenance and Troubleshooting 57
can cause the material to slip, resulting in inaccurate cuts or incorrect
material transport.
For a light cleaning, brush them with a soft-bristle brush, such as a
paintbrush or toothbrush. While brushing, rotate the rollers manually to
make sure they are clear of paper dust and thoroughly clean.
For a more thorough cleaning, run an 18" long piece of 1½ " masking
tape between each drive roller and a pressure roller (in the down
position) with the adhesive side towards the drive roller.
To remove material particles from the cutter blade in a standard knife holder
Use following procedure to remove small material particles in the base of
the cutting blade holder.
1. Take the body (2) into one hand and unscrew the base (1).
2. Blow away the material particles accumulated in the top of the base.
3. Remove the spring from the cutting blade and remove any residual
material from the blade tip.
4. Place the spring back over the cutting blade and tightly screw the base
on the holder.
To remove material particles from the cutter blade in an optional knife holder with
vernier
1. Take the ring in your hand and remove the base.
2. Blow away the material particles accumulated in the top of the base.
3. Remove any residual material from the blade tip.
