Chapter 5, Cutter Maintenance and Troubleshooting 71
Language errors
Language errors occur when command data from the host computer does
not match the data format of the command mode currently activated on
the cutter’s side. The error can be caused by a difference in command
type or by a syntax error.
Use the Error Code chart below to determine the error code being
displayed by the LED bar. Then use the chart at the bottom of the page to
determine the possible cause and corrective action.
ERROR CODE
10% 20% 30% 40% 50% 60% 70% 80% 90% 100%
UNDEFINED XX
E01
ERROR PARAMETER
E02
ERROR VALUE
E03
UNKNOWN CHAR
E05
BUFFER OVERFLOW
E07
POSSIBLE CAUSE and SUGGESTED ACTION
E01 Undefined MH-GL/2 command. Verify computer and cutter language
settings.
E02 Incorrect number of parameters was
transmitted.
E03 Parameter out of range was transmitted.
E05 Character unknown to MH-GL/2 was sent.
E07 Polygon and character buffer overflow.
Verify computer and cutter language
settings.
