32 Chapter 3, Cutter Settings and Special Functions
CHAPTER 3
CUTTER SETTINGS and SPECIAL FUNCTIONS
INTRODUCTION
Most of the frequently-used settings are available directly from the
keyboard. However, when setting up the cutter, you must fine tune it to
match the computer setup. Furthermore, the MENU mode operation gives
you access to the setup sheet, allowing you to change special functions
that are not used frequently.
This chapter contains information on how to enter the MENU mode, plot
the setup sheet, and use it to change 32 different settings.
CHANGING THE USER LANGUAGE
It is possible to change the user language of your cutter, thus changing
the setup sheet language. This can be done by pressing two keys
simultaneously during power-up. The combinations are:
LANGUAGE KEY COMBINATION
American (Default)
ENTER + SLEW DOWN
German
ENTER + SLEW UP
French
ENTER + SLEW RIGHT
English
ENTER + SLEW LEFT
Japanese
ENTER + ONLINE
MENU MODE OPERATION
1. Install a PEN in the tool head.
2. For optimum plot quality, set the tool selection to a PEN (factory
default TOOL3 and 4).
3. Load a B-size (11" X 17") sheet of paper or larger into the cutter with
the short side on the Y-axis.
4. Switch the cutter to
offline
by pressing the ONLINE key.
The ONLINE LED indicator should go off.
5. Enter the MENU mode by pressing ENTER and slew À (SETUP).
