Chapter 2, Cutter Controls 27
SPEED SELECTION
The speed selection allows you to set the tool-down speed, the speed at
which the tool moves through the material.
1. Switch the cutter
offline
.
2. Using the MENU selection keys, select the SPEED option (LED next to
SPEED must be on).
The current SPEED setting for the selected tool is shown on the LED
bar. You can view the value both offline as and online modes.
3. Use the VALUE +/- keys to change the SPEED setting.
4. Press ENTER to confirm and store, or press one of the menu keys to
exit.
The indicated value only refers to the tool-down speed of the selected tool.
The tool-up speed can be set separately (See Tool Selection page 23, in
this Chapter.
All values being used or available are shown in the tables at the end of
this chapter.
ACCELERATION SELECTION
1. Switch the cutter
offline
.
2. Using the MENU selection keys, select the ACCELERATION option
(LED next to ACCELERATION must be on).
The current ACCELERATION setting for the selected tool is shown on
the LED bar. You can view the value in both offline and online modes.
3. Use the VALUE +/- keys to change the ACCELERATION settings.
4. Press ENTER to confirm and store, or press one of the menu keys to
exit.
All values being used or available are shown in the tables at the end of
this chapter.
PAGE LENGTH
This parameter is related to loading roll material. The PAGE LENGTH
must be set before a roll is loaded. Set the PAGE LENGTH to a value at
least as large as the job you are going to cut.
