3.2.3.3.1.2 Analog Input Manual
A list of analog inputs that can be calibrated is displayed.
000598
TEMP CHAMBER
TEMP IND CHA.
To change the gain or offset of an input, select the desired value
field and press .
A window is displayed with an editable field for the value. Edit by
using the cursor keys.
Press to save the low value. The previous window is displayed
again.
Select at the bottom of the list and press to save the
settings.
3.2.3.3.1.3 Dose Monitor Automatic
A list of dose monitors that can be calibrated is displayed. To
calibrate:
1. Select the status field for the dose monitor that you would like
to calibrate and press .
Type Unit FactorAutocal.
Time
Desired
2. A window with the option of entering the desired volume is
displayed. To edit the desired value, select the value and
press .
3. A window with an editable field for the desired value is
displayed. Edit by using the cursor keys. Press to change
the value. The previous window is displayed again.
4. Select and press to continue.
5. The dosing pump starts and a window providing the option of
entering the measured volume is displayed.
6. If the dosing pump has stopped, enter the measured volume
in the same way as with the desired volume.
7. Select and press to continue.
8. Calibration complete.
3 MENU TREE
TECHNICAL MANUAL GETINGE WD15 CLARO 33 (128)
<Doc_TEC><Doc_6001396902><Rev.I><Lang_en>
