3.2.3.3.1.4 Dose Monitor Manual
A list of dose monitors that can be calibrated is displayed. To
change the calibration factor:
1. Select the desired factor and press .
2. A window is displayed with an editable field for the calibration
factor. Edit by using the cursor keys. Press to change the
value. The previous window is displayed again.
3. Select
at the bottom of the list and press to save the
settings.
3.2.3.3.2 Diagnostics
3.2.3.3.2.1 Analog inputs
A list of current values for the system’s analog inputs is displayed.
The values are continuously updated.
3.2.3.3.2.2 Analog outputs
There are no analog outputs for this type of machine.
3.2.3.3.2.3 Digital inputs
A list of current values for the system’s digital inputs is displayed.
The values are continuously updated.
3 MENU TREE
34 (128) TECHNICAL MANUAL GETINGE WD15 CLARO
<Doc_TEC><Doc_6001396902><Rev.I><Lang_en>
