3.2.3.3.2.4 Digital outputs
A list of current values for the system’s digital outputs is displayed.
The values are continuously updated.
The user can choose to set the outputs to automatic or manual
mode.
In automatic mode, the outputs’ status is controlled by the outputs
of the application program.
In manual mode, the user can manually affect the status of the
outputs both in standby mode or while the process is happening.
• To switch between manual and automatic mode, select the
key for Alternative for desired output and press to change
the mode. You can now set the output status.
• To set the status, select the value field and press . A
window is displayed with an editable field for the status. Edit
by using the cursor keys. Press to save the status. The
previous window is displayed again.
• Select at the bottom of the list and press to save the
settings.
3.2.3.3.2.5 System flags
A list of system flags and their status is displayed.
3.2.3.3.2.6 User flags
A list of all the system’s user flags is displayed.
3 MENU TREE
TECHNICAL MANUAL GETINGE WD15 CLARO 35 (128)
<Doc_TEC><Doc_6001396902><Rev.I><Lang_en>
