11.2 Ventilator
11.2.1 General
Dimensions (mm)
• Patient Unit: W 380 x D 300 x H 210
• User Interface: W 355 x D 53 x H 295
- Screen type: TFT-LCD module
- Screen size: 31 cm (12.1") diagonal
- Viewing area: 246.0 x 184.5 mm
Weight, approximate (kg)
20
Triggering method
• Flow and pressure
11.2.2 Gas supply
Gas quality
Supplied gases shall meet the requirements
for medical grade gases according to
applicable standards.
Maximum levels
Air
• H
2
O < 7 g/m
3
• Oil < 0.5 mg/m
3
• Chlorine: must not be detectable
3
Oxygen
• H
2
O < 20 mg/m
3
• Oil < 0.3 mg/m
3
Inlet gas
• Pressure: 2.0 – 6.0 kPa x 100 (29 – 87 psi)
• max 60 l/min
Connection standards available
AGA, DISS, NIST, or French.
Unavailable gas/loss of gas pressure
The flow from an unavailable gas (air or O
2
) is
automatically compensated for so that the
patient gets the preset volume and pressure.
11.2.3 Patient System Connectors
Conical fittings (mm)
Male 22 and female 15, in accordance with
ISO 5356-1.
Gas exhaust port (mm)
Male 30 cone.
3. If the compressed air is generated by a liquid ring compressor there is a potential risk of chlorine in the supplied
air.
148
SERVO-s VENTILATOR SYSTEM V8.0, User's Manual
| 11
| Technical data |
