11.9 Alarms
11.9.1 Alarm limits
Audio Off (only
for NIV)
Setting range
Factory set
default
Parameter
No16 - 12040Airway pressure, upper limit (cmH
2
O)
6
No16 - 7020Airway pressure, upper limit (cmH
2
O) in
NIV
7
No15 - 4520Apnea time to alarm (s)
Ye s0 - 472End expiratory pressure, high limit
(cmH
2
O)
8
Ye s0 - 5510End expiratory pressure, lower limit
(cmH
2
O)
Ye s0.5 - 40.05.0Expired minute volume, lower limit (l/min)
Ye s0.5 - 60.040.0Expired minute volume, upper limit (l/min)
Ye s1 - 1605Respiratory rate, lower limit (b/min)
Ye s1 - 16030Respiratory rate, upper limit (b/min)
NoSet value - 5 vol%
or
18 vol%
-O
2
concentration low
NoSet value + 5 vol%-O
2
concentration high
--<2.0 kPa x 100 or
>6.0 kPa x 100
Gas supply
NoObstruction leading
to constant high
airway pressure
(>PEEP +15
cmH
2
O) during:
• > 2 breaths or 5
seconds,
whichever is
greater,
• 15 ±1.5 s if less
2 breaths are
triggered
-High continuous pressure
6. If P
aw
rises 6 cmH
2
O above the set limit or if system pressure exceeds 117 ±7 cmH
2
O, the safety valves opens.
7. If P
aw
rises 6 cmH
2
O above the set limit or if system pressure exceeds 117 ±7 cmH
2
O, the safety valves opens.
8. Setting the alarm limit to 0 (zero) is equivalent to turning off the alarm.
SERVO-s VENTILATOR SYSTEM V8.0, User's Manual
155
