11.15 Service
WARNINGS!
• Preventive maintenance must be
performed by authorized personnel at
least once a year or after every 5000
hours of operation. The Status menu on
the user interface shows the current
operating time.
• Service, repair and installation must only
be performed by personnel authorized
by the manufacturer.
• All technical documentation is available
for use by personnel authorized by the
manufacturer.
• Service mode should only be used
without a patient connected to the
ventilator.
CAUTION:
Original parts from the manufacturer must
be used.
Battery module replacement, see page 38 for
information.
11.16 Accessories
11.16.1 Mobile Cart (Option)
Weight (kg)
25
Dimensions (mm)
W 500 x L 650 x H 830
with handles 1030
11.16.2 Shelf Base (Option)
Weight (kg)
0.1
Dimensions (mm)
W 80 X L 160 X H 8
11.16.3 Compressor Mini (Option)
Dimensions (mm)
W 430 x D 330 x H 250
Weight (approximate, kg/lbs)
26/70
Power supply
115 V AC, 60 Hz (single phase).
220–240 V AC, 50/60 Hz (single phase).
Compressor capacity
Continuous flow at normal atmospheric
pressure (approximately 1013 hPa) 30 l/min
(expanded to ambient air pressure) at 3.5 kPa
x 100 (bar)/50 psi.
11.16.4 Servo Duo Guard
For further information, see the Servo Duo
Guard User's Manual.
SERVO-s VENTILATOR SYSTEM V8.0, User's Manual
159
| Technical data |
11 |
