5.2.2 Pressure Control
V
V
P
1
2
3
4
5
6
7
8
10
9
I:E
X
Z
t
t
t
X. Inspiration time
Z. Expiration time
Pressure-time waveform
1. Start of Inspiration
2. Peak inspiratory pressure
3. End expiratory pressure
Flow-time waveform
4. Peak inspiratory flow
5. End inspiratory flow
6. Peak expiratory flow
7. End expiratory flow
Volume-time waveform
8. Start of inspiration
9. End inspiration
10. End expiration
