4.5 Show trends
Trend values are stored every 60 seconds and
retained as far back as 24 hours. Stored
events and system changes are shown as
event stamps.
SVS-5016_XX
To show trends:
1. Press the Trends fixed key.
2. Use the up and down arrows to scroll
between the different trend channels.
3. To quit the Trends Window press Close.
4. To adjust the time resolution press the
Hours touchpad and turn the Main Rotary
Dial.
5. Activate the Cursor. Move it back and
forth on the time axis using the Main
Rotary Dial or touch screen.
6. Time valid for the cursor position. For
event stamps, an explanation appears.
7. Logged event stamps.
SERVO-s VENTILATOR SYSTEM V8.0, User's Manual
49
