Additional settings
Press the Additional settings touchpad to see the settings available for the
current mode.
Vital parameters are set using the Direct Access Knobs.
The bar below the numeric value is a graphical representation of the chosen
value and gives information about the parameter ranges.
• the bar is white if your setting is within what is generally considered safe
ranges
• the bar turns yellow if your setting is slightly beyond what is generally
considered safe ranges
• the bar turns red if your setting is significantly beyond what is generally
considered safe ranges
I:E/Insp. times
The trigger sensitivity bar is colored based on the setting:
• the bar is green for a normal setting for flow triggering
• the bar is red when there is a risk of self-triggering
• the bar is white when pressure triggering is selected.
Note: If there is leakage in the breathing system, e.g. if an uncuffed
endotracheal tube is used, triggering will then be initiated by the system
and not by the patient.This should always be avoided by decreasing the
trigger sensitivity.
Trigger
This touchpad will be visible in supported ventilation modes.Backup ventilation
This is an area of the screen which shows which shows measured/calculated
numerical values.
Values will be presented on two pages (three pages if Lung Mechanics option
is installed). By pressing Additional values it is possible to scroll between the
pages.
Note: In NIV, only one page is available.
Additional values
SERVO-s VENTILATOR SYSTEM V8.0, User's Manual
177
| Appendix • User interface |
13 |
