GWN76XX User Manual
Version 1.0.19.25
SYSTEM
Settings
Users can access Maintenance page from GWN76XX WebGUISystem Settings.
Basic
Basic page allows Country and Time configuration.
Table 30: Basic
Anti-domain name hijacking protection. If enabled, when the address
returned by the superior DNS is a private LAN address, it will be regarded as
a domain name hijacking, thus discarding the analytical result. If disabled,
the analytical results will not be discarded.
Due to the security enhancement, unless Legacy TLS Compatibility (only
available on 1.0.15.4 or higher version) is enabled, master AP on 1.0.15.4 or
higher firmware will not compatible with slave AP on firmware lower than
1.0.15.4. Master AP on firmware lower than 1.0.15.4 will also not be
compatible with slave AP on firmware 1.0.15.4 or higher. Cloud and GWN
Manager will still support both firmwares. Default is enabled.
Enables Web HTTP Access. By default, it’s disabled.
Specifies HTTPS port.
By default, is 443.
Select the country from the drop-down list. This can affect the number of
channels depending on the country standards.
Depending deployment type (Indoor or Outdoor) then additional 5Ghz
channels (DFS Channels) will be available to be used. Please refer to table
DFS Channels supported by Model.
Configure time zone for the GWN76XX.
Make sure to reboot the device to take effect.
Configure the IP address or URL of the NTP server. The device will obtain
the date and time from the configured server.
Change the Date Display Format, three options are possible YYYY/MM/DD,
MM/DD/YYYY and DD/MM/YYYY.
