GWN76XX User Manual
Version 1.0.19.25
3. Click on Pair under Actions, to pair the discovered access point as slave with the GWN76XX
acting as Master.
4. The paired GWN76XX will appear Online, users can click on to unpair it.
Figure 36: GWN76XX Online
5. Users can click on next to Master or paired access point to check device configuration for
its status, users connected to it and configuration. Refer to below table for Device Configuration
tabs.
6. Now an easier way to transfer your master authority from one unit to another available unit is
available on Access Point management page. By clicking the then
“Transfer
to Master” button the designated slave unit will be upgraded to master and current master will
be downgraded to slave accordingly.
Table 12: Device Configuration
Shows the device’s status information such as MAC, Product Model, Part
Number, Boot Version, Firmware version, IP Address, Link Speed, Uptime,
and Users count via different Radio channels.
Shows the connected users to the GWN76XX access point.
Device Name: Set GWN76XX’s name to be shown next to MAC
address.
Fixed IP: Set a static IP for the GWN76XX, default is unchecked.
Airtime Fairness: Allow faster clients to have more airtime than
slower clients. This feature is not supported in GWN7630/7630LR.
Band Steering: When Frequency is set to Dual-Band, users can
check this option to enable Band Steering on the Access Point, this
will help redirecting clients to 5G band accordingly for efficient use
and to benefit from the maximum throughput supported by the client.
NET Port Type: You can configure Trunk port or Access port. If you
chose Access, you also need to specify its VLAN ID. This feature is
not supported in GWN7600/7600LR/GWN7610.
Client Steering: This feature will help Wi-Fi client to roam to other
APs within same Network. parameters of RSSI Threshold and Client
Access Threshold parameters will show up only when Client
Steering is enabled. Supported only by GWN7600/7600LR.
