P a g e | 39

GWN76XX User Manual

Version 1.0.19.25

Below is the equipment packaging for GWN7600LR model.

Table 7: GWN7600LR Equipment Packaging

Main Case

Yes (1)

Cover Interface

Yes (1)

Base Bracket

Yes (1)

Cover Bracket

Yes (1)

Assembled Screw

Yes (4)

Locknut

Yes (4)

Anchors + Screws

Yes (4)

Screw (PM8 x 115)

Yes (4)

Quick Installation Guide

Yes (1)

GPL License

Yes (1)

Figure 2: GWN7600LR Equipment Package
