GWN76XX User Manual
Version 1.0.19.25
ACCESS POINTS
From the access points page, the administrator can monitor different information regarding the access
points of the selected network, this section is separated into 3 sub-sections:
1. Status
2. Configuration
Status
The Status page lists all the access points assigned to the selected network, along with the possibility to
perform some basic operations such locating the device (LEDs start blinking in White) or clear the usage
data, also users can check more detailed information about each access point and benefit from useful
debugging tools which can help diagnose issue when they appear.
Figure 48: Access Points - Status
Table 13: Access Points Status Parameters
Model
GWN Access Point Model: GWN7610, GWN7600, GWN7600LR or GWN7630 (Beta)
MAC
MAC Address of the Access Point
Name
Access Point’s name
IP Address
IP Address of the Access point
Firmware
Firmware of the Access point
Uptime
Uptime of the Access point
Channel
Channels used by this Access points for both 2G and 5G.
Client
Number of clients connected to the Access Point
Actions
Locate Access point using button.
Press to clear access point usage.
Press to switch slave access point to become master.
