Grandstream Networks GWN76 Series - Installation

P a g e | 38
GWN76XX User Manual
Version 1.0.19.25
INSTALLATION
Before deploying and configuring the GWN76XX, the device needs to be properly powered up and
connected to the network. This section describes detailed information on installation, connection and
warranty policy of the GWN76XX.
Equipment Packaging
Table 6: GWN7630/GWN7610/GWN7615/GWN7605/GWN7600 Equipment Packaging
Main Case (GWN7630 or GWN7610 or
GWN7615 or GWN7605 or GWN7600)
Yes (1)
Mounting Bracket
Yes (1)
Ceiling Mounting Bracket
Yes (1)
Plastic Expansion Bolt
Yes (3)
M3 NUT
Yes (3)
Screw (PM 3 x 50)
Yes (3)
Screw (PM 3.5 x 20)
Yes (3)
Quick Installation Guide
Yes (1)
GPL License
Yes (1)
GWN7605/7615 No
Figure 1: GWN7630 or GWN7610 or GWN7605 or GWN7600 Equipment Packaging
GWN7630 / GWN7610 / GWN7605 / GWN7600
