Grandstream Networks GWN76 Series User Manual

P a g e | 47
GWN76XX User Manual
Version 1.0.19.25
GETTING STARTED
The GWN76XX Wireless Access Point provides an intuitive web GUI configuration interface for easy
management to give users access to all the configurations and options for the GWN76XX’s setup.
This section provides step-by-step instructions on how to read LED patterns, discover the GWN76XX and
use its Web GUI interface.
LED Patterns
The panel of the GWN76XX has different LED patterns for different activities, to help users read the status
of the GWN76XX whether it’s powered up correctly, provisioned, in upgrading process and more, for more
details please refer to the below table.
Table 10: LED Patterns
LED Status
Indication
OFF
Unit is powered off or abnormal power supply.
Blinking green
Firmware update in progress.
Solid green
Firmware update successful.
Blinking red
Delete paired slave - Factory reset initiated.
Solid red
Firmware update failed.
Solid purple
Unit not provisioned.
Blinking blue
Unit provisioning in progress.
Solid blue
Unit is provisioned successfully.
Blinking White
Used for Access Point location feature
Yellow
Mesh disconnection.
