WR1000-UM-251-01-9380 7-9
(2) Parts list for the main unit
No. Part no. Name Remarks
1 601100041 Upper Amp Chassis
2 601100021 Rear Plate
3 601100011 Front Plate
4 601100002 Main Chassis
5 601100230 Amp Bottom Cover
601100221 Printer Unit Mold
6
601900351 Hi-temp Caution Label
7 601100080 Guide Rail Bracket
8 770110114 AC Input Assy
9 601100090 DC Reinforcement Plate
10 795900105 9000 Fan Assy
11 601100051 Power Chassis
500002817 FDD (YD-702D-6539)
500002847 MODD (M2313A68-1) Production discontinued
12
500002957 MODD (MCB3064SS)
500003106 HDD (DDRS39130-F20W68) Production discontinued
13
500003118 HDD (DENS-309170W-F20)
14 770110113 System Power Board
15 500002907 Amp AC/DC Select Board 100V/200V For CH 1-8
16 500002908 Amp AC/DC Select Board 100V/200V For CH 1-16
17 680110172 Amp AC/DC Board
18 601100030 Amp Mother Board Mounting Plate
770110117 Amp Mother Board For CH 1-8
19
770110111 Amp Mother Board For CH 1-16
20 This number not used
21 770110110 Main Control Board
22 770110116 16CH Control Board For CH 9-16
23 770110129 FDD Control Board
24 770110305 SCSI Control Board
25 This number not used
795900103 9000 Battery Board Assy
26
500002212 Battery, ML2430-TT1
27 301001005 Guide, GR-80S
28 770110114 AC Relay Board
Fig. 7-3-1
To Next Page
