3. DISASSEMBLY AND REASSEMBLY
3.9.2 Replacing the Magneto-Optic Disk Drive (MODD) and SCSI Control Board
Replacing the MODD
The procedure for replacing the MODD is identical to that for replacing the FDD, so see the explanation under
“Replacing the FDD” in Subsection 3.9.1, “Replacing the FDD and FDD Control Board.”
Although the WR1000 can use the same disk drives as the WR9000 and WR8500, heed the differ-
ences in the settings shown below during the replacement process.
(Production of the M2513A68-1 Bezel has already been discontinued but, since it can be mounted on
the WR1000, it has been listed below for your reference.)
a. M2513A68-1 Bezel
Fig. 3-9-4
b. MCB3064SS
Fig. 3-9-5
