WR1000-UM-251–01–9380 3 – 12

3. DISASSEMBLY AND REASSEMBLY

3.3.4 Replacing and Cleaning the Control Panel Keys

The control panel keys of the WR1000 consist of two types of keys: sheet keys (for amp control panel keys)

and rubber switch-keys (for main control panel keys and menu keys).

Replacing Sheet Keys and Menu Sheets

Either replace the pertinent sheet as required or replace the entire control panel cover.

Fig. 3-3-14

G logo plate

Amp control panel sheet

Main control panel sheet
