GRAPHTEC WR1000 - Other Accessories and Options

WR1000-UM-251–01–9380 1 – 2
1. CONFIGURATION
1.4 Other Accessories and Options
Table 1-4-1. Other accessories and options
Name Part no. Remarks
Voltage measurement amp V amp 2 channels/unit
Voltage/temperature measurement amp M amp 2 channels/unit
Logic measurement amp LO amp 16 channels/unit
GP-IB interface B-387
Long-length Z-fold chart unit B-392 Mounted at the bottom of the main unit for use
Internal Z-fold chart unit B-405 Z-fold chart unit that can be stored inside the
main unit
Writing table B-393 For writing comments, etc. on chart paper
Floating voltage input probe CM-105
Voltage fluctuation probe CM-106
Probe for the logic amp RIC-07 For the logic amp
Alligator clip cable RIC-08 For the logic amp
IC clip cable RIC-09 For the logic amp
Probe set RIC-10 Kit including RIC-07, -08, and -09; for the logic
amp
Input cables with 2-pin banana plugs B-378 Set of 2 cables (RIC-115), bare tips
B-336 Set of 4 cables (RIC-115), bare tips
B-331 Set of 8 cables (RIC-115), bare tips
B-335 Set of 16 cables (RIC-115), bare tips
BNC-BNC cable RIC-112 1.5 m, BNC adapter required
BNC-banana plug cable RIC-113 1.5 m, BNC adapter required
BNC-alligator clip cable RIC-114 1.5 m, BNC adapter required
AC power cord RSC-110 2-m cord with 3-pin plugs
DC power cord RIC-140 2-m cord with 10-pin round connectors
Clamp adapter CM102 Alternating current, 0 to 1200 A; 1 channel
Digital clamp meter CM-111 AC/DC/voltage, resistance, frequency,
temperature; one channel
Line separator CM-108 Magnification factors: ×1, ×10; compatible with
parallel-pin plug
Temperature probe for clamp meter RIC-110 Temperature range: - 30 to 200°C (for use with
CM-111)
REMOTE connectors RCN-114 16-pin connector jacks
BNC adapters SMA-101-4P A set of 4 banana-BNC conversion adapters
Safety conversion adapter SMA-102 An adapter for converting a high-voltage banana
plug into a BNC plug
