WR1000-UM-251-01-9380 7-12
(2) Parts list for the control unit
No. Part no. Name Remarks
1 601100401 Control Panel Mold
2 621120070 G Logo Plate
3 601100410 Protective Plate
4 601100420 Vertical Protective Plate Spacer
5 601100430 Horizontal Protective Plate Spacer
6 500003071 LCD [TFT] (LTM10C209A)
7 106600270 Control Panel Keytop
8 601900340 Rubber Switch
9 601100481 Conditions Panel Key Assy
10 601100500 JOG dial G5
11 601100490 JOG shuttle G5
12 601100470 Main Control Panel Sheet
13 601100520 Amp Control Panel Sheet
14 770110124 Key Control Board
15 601100451 LCD Shield Plate
16 601100530 Control Panel Shield
17 601100441 Control Panel Mounting Plate
18 500003107 E04FA80340120
19 690110550 FC, WR1000-05
LCD RELAY KEY CONT
20 690110511 FC, WR1000-01A
MAIN CONT KEY CONT
21 690110530 FC, WR1000-03
MAIN KEY KEY CONT
22 690110540 FC, WR1000-04
MENU KEY KEY CONT
23 690110100 CA, WR1000-10
inverter KEY CONT
24 770110121 Main Control Panel Key Board
25 770110122 Conditions Panel Key Board
26 500003072 Inverter Board
27 770110125 LCD Relay Board
28 601900620 GND Cable Label
A M3L4 Binding-head Screw
B M3L6 Binding-head Screw
C M3L6 Tapping Screw
D M2.6L4 Binding-head Screw
Fig. 7-4-1
To Next Page
