WR1000-UM-251–01–9380 4 – 4
4. SETUP PROCEDURES
(8) When the prompt below appears, individually set the measurement precision for each range. Specify the
voltage generator’s output voltage setting to correspond to one of the displayed voltage Ranges in the
following table, and then input that voltage to the WR1000.
50mV:
[
Start
]
to exec.
Fig. 4-4-4
Table 4-4-1
Displayed Range setting Output voltage setting
50 mV 50.00 mV
100 mV 100.0 mV
200 mV 200.0 mV
500 mV 500.0 mV
1 V 1.000 V
2 V 2.000 V
5 V 5.000 V
500 V 500.0 V
Sequentially repeat Steps (7) and (8) for each Range listed in the preceding table, from 50mV through
500 V.
(9) When you have finished the Setup operation for 500V, the prompt below appears.
EEPROM:
[
Exec
]
to start
Fig. 4-4-5
(10) Press the
EXECUTE
key at the Conditions panel to begin writing the new Setup data to the EEPROM of
each amp.
(11) Turn off the WR1000.
This completes the setup of the V type amp(s).
