Gtec SATURN - Page 112

- 112 -
➢ Fault: more critical problems than “Anomalies” in that, if they persist, they may bring the CPS to a halt.
CODE
DESCRIPTION
F01
Internal communication error
F02
Incorrect input phase direction.
F03
Input fuse 1 broken or input relay blocked (will not close)
F04
Input fuse 2 broken or input relay blocked (will not close)
F05
Input fuse 3 broken or input relay blocked (will not close)
F06
Input relay 1 blocked (always closed)
F07
Input relay 2 blocked (always closed)
F08
Input relay 3 blocked (always closed)
F09
Precharge of positive branch capacitors failed
F10
Precharge of negative branch capacitors failed
F11
BOOST stage anomaly
F14
Sine wave of inverter distorted
F17
Inverter stage anomaly
F19
Positive battery overvoltage
F20
Negative battery overvoltage
F21
Positive battery undervoltage
F22
Negative battery undervoltage
F23
Overload at output
F26
Output relay 1 blocked
F27
Output relay 2 blocked
F28
Output relay 3 blocked
F29
Output fuse 1 blown
F30
Output fuse 2 blown
F31
Output fuse 3 blown
F32
Battery charger stage anomaly
F33
Output fuse of battery charger blown
F34
Heat sink overtemperature
F37
Battery charger overtemperature
F42
BOOST battery 1 fuse blown
F43
BOOST battery 2 fuse blown
F44
BOOST battery 3 fuse blown
F48
Battery anti-inversion system failure
