APS-7000 Series User Manual
98
0ms: Stays high/low.
9. If Width, above, was set 0ms, you can choose
the output pin polarity with the Level
parameter. This setting will pull the output pin
high or low when source condition is true.
This setting is not available when Width is set
to 1~60ms.
Level
HI (≥+2V), LO(≤+0.8V)
Exit
10. Press Exit[F4] to exit from the
Trigger Control settings.
