GW Instek GDS-2000 Series User Manual

GDS-2000 Series User Manual
10
GETTING STARTED
This chapter describes GDS-2000 in a nutshell,
including its main features and front / rear panel
introduction. After going through the overview,
follow the Set Up section to properly set up
operation environment.
GDS-2000 series
overview
Series lineup ...................................................11
Main Features ..................................................12
Package Contents ............................................13
Appearance GDS-2064/2104/2204 Front Panel ....................14
GDS-2062/2102/2202 Front Panel ....................14
Rear Panel .......................................................18
Display ............................................................20
Set Up Tilt stand .........................................................22
Power up .........................................................23
First Time Use .................................................24

GW Instek GDS-2000 Series Specifications

General

Brand	GW Instek
Model	GDS-2000 Series
Category	Test Equipment
Language	English
