GDS-2000 Series User Manual
146
PRINT OUT
Display printout is also available using proprietary PC software,
downloadable from GWInstek website.
Overview
Printout step
Listed below are the steps that have to be followed
when printing out the display image through USB
connector.
1. Connect the printer to the USB host port
2. Configure the interface to printout mode
3. Configure the content and printout
4. Printout
1 Connect printer
1. Connect the printer to the USB host port, front
or rear panel.
Front panel
Rear panel
USB Note
Using the front and rear USB host port at the same
time is forbidden (Example: printer to the rear
panel, storage device to the front panel).
To Next Page
