GW Instek GDS-2000 Series User Manual

GDS-2000 Series User Manual
122
Setup file format
Format
DSxxxx.set or Axxxx.set (proprietary format)
The setup file saves or recalls the following setting.
Contents
Acquire
 mode  memory length
Cursor
 source channel
 cursor location
 cursor on/off
Display
 dots/vectors
 grid type
 accumulation
on/off
Measure
 item  source channel
Utility
 hardcopy type
 interface type
 buzzer type
 Go-NoGo cond.
 ink saver on/off
 RS-232 config
 GPIB address
 menu language
Program
 step contents
 start/stop steps
 loop count
Horizontal
 display mode
 position
 scale
Trigger
 trigger type
 trigger mode
 video polarity
 pulse timing
 source channel
 video standard
 video line
 slope/coupling
Channel
(vertical)
 vertical scale
 coupling mode
 bandwidth limit
on/off
 vertical position
 invert on/off
 probe
attenuation
Math
 operation type
 vertical position
 FFT window
 source channel
 unit/div
