GW Instek GDS-2000 Series User Manual

GDS-2000 Series User Manual
142
Recall waveform
Panel operation
1. (For recalling from an
external USB flash drive)
Connect the drive to the
front or rear panel USB port.
Note: Only one host
connection, front or rear, is
allowed at a time.
Front
Rear
2. Press the Save/Recall key.
Save/Recall
3. Press F5 (More).
More
F 5
4. Press F4 (Recall Waveform).
The display shows the
available source and
destination options.
Recall
Waveform
F 4
