GW Instek GDS-2000 Series User Manual

GDS-2000 Series User Manual
150
Interface Configuration
Configure USB interface
USB
configuration
PC side connector
Type A, host
GDS-2000 side
connector
Type B, slave
Speed
1.1/2.0 (full speed)
Panel operation
1. Press the Utility key.
Utility
2. Press F2 (Interface Menu).
Interface
Menu
F 2
3. Press F1 (Type) repeatedly
to select USB.
Type
USB
F 1
4. The interface icon at the top
of the display changes into
USB type.
5. Connect the USB cable to
the rear panel slave port.
6. When the PC asks for the USB driver, select
gds2k_cdc.inf included in the FreeWave
software package downloadable from GW
website, www.gwinstek.com
, GDS-2000
product corner. The driver file automatically
sets GDS-2000 as serial port COM7.
