GDS-2000 Series User Manual
78
Program
Overview
Background
Program function measures input signals using
cursors or automatic measurement functions, in
user-defined sequence, duration, loop count, and
panel settings. This feature is useful for automated
and repetitive measurement, such as in assembly
line or quality inspection test.
Parameter Program set
1 set
Program step
Maximum 20 steps
Measurement
item
Cursor or Automatic
measurement
Time (duration)
per step
1 ~ 99 seconds, or user activation
Program loop
1 ~ 99 loops, the first and last step
settable
Programming
step
1. Show the target waveform on the display and
decide the type of measurement that needs to
be done: Horizontal/Vertical Cursor or
Automatic measurement.
2. Setup the other panel configurations: trigger,
acquisition, horizontal/vertical scale, etc. Save
the settings to the internal memory. See
page129 for details.
3. Edit the program (page79) using the internally
stored panel setup.
4. Run the program (page81).
