GW Instek GDS-2000 Series User Manual

GDS-2000 Series User Manual
12
Main Features
Performance
 High sampling rate: up to 1GS/S real-time,
25GS/s equivalent-time
 Deep memory: 25k points record length
 Minimum 10ns peak detection
Feature
 Wide selection range: 60MHz to 200MHz
bandwidth, 2 or 4 channels
 Powerful display: 5.6 in. color TFT, wide
viewing angle, 8x12 divisions waveform
support
 Battery operation
 Automatic measurements: maximum 27 types
 FFT analysis
 Triggers: Edge, Video, Pulse Width
 Advanced Delay trigger (for 2CH model only)
 Program and play mode
 Color printout of display contents
 Go-No Go test
 Built-in Help
Interface
 USB host port: front and rear panel, to printers
and storage devices
 USB slave port, RS-232C port, GPIB port
(option): for remote control
 USB slave port for PC software connection
 Calibration output
 Go-No Go output
 External trigger input (for 2CH model only)

GW Instek GDS-2000 Series Specifications

General

Brand	GW Instek
Model	GDS-2000 Series
Category	Test Equipment
Language	English
