GW Instek GDS-2000 Series User Manual

GDS-2000 Series User Manual
166
GDS-2000 Specifications
The specifications apply when GDS-2000 is powered on for at least
30 minutes under +20°C~+30°C.
Model-specific
GDS-2062 Channels 2
Bandwidth DC ~ 60MHz (–3dB)
Rise time 5.8ns approx.
GDS-2064 Channels 4
Bandwidth DC ~ 60MHz (–3dB)
Rise time 5.8ns approx.
GDS-2102 Channels 2
Bandwidth DC ~ 100MHz (–3dB)
Rise time 3.5ns approx.
GDS-2104 Channels 4
Bandwidth DC ~ 100MHz (–3dB)
Rise time 3.5ns approx.
GDS-2202 Channels 2
Bandwidth DC ~ 200MHz (–3dB)
Rise time 1.75ns approx.
GDS-2204 Channels 4
Bandwidth DC ~ 200MHz (–3dB)
Rise time 1.75ns approx.
Common
Vertical Sensitivity 2mV/div~5V/Div (1-2-5 increments)
Accuracy ± (3% x |Readout|+0.05div x Volts/div +
0.8mV)
Input Coupling AC, DC, Ground
Input
Impedance
1MΩ±2%, ~16pF
Polarity Normal & Invert
Maximum Input 300V (DC+AC peak), CAT II
Math operation +, –, FFT
Offset Range 2mV/div~20mV/div: 0.5V
50mV/div~200mV/div: 5V
500mV/div~2V/div: 50V
5V/div: 300V
Bandwidth Limit 20MHz (−3dB)
