Default Settings
Here is the factory installed panel setting which
appears when pressing the Save/Recall key→F1
(Default Setup).
Save/Recall
Default
Setup
F 1
Acquisition
Mode: Normal Memory length: 500
Channel
Scale: 2V/Div CH1: On, CH2/3/4: Off
Coupling: DC Invert: Off
BW limit: Off Probe attenuation: x1
Cursor
Source: CH1 Horizontal: None
Vertical: None
Display
Accumulate: Off
Graticule:
Go-NoGo
Go-No: Off Source: CH1
Violating: Stop
Horizontal
Scale: 2.5us/Div Mode: Main
Math
Type: + (Add) Channel: CH1+CH2
Position: 0.00 Div Unit/Div: 2V
Math Off
Measure
Source1, 2: CH1, CH2 Type: VPP, Avg, Freq,
Duty Cycle, Risetime
Program
Mode: Edit Step: 1
Trigger
Type: Edge Source: Channel1
Mode: Auto Slope:
Coupling: DC Rejection: Off
Noise Rejection: Off
Utility
Square wave probe, 1k,
50% duty cycle
Hardcopy: save image,
ink saver on
Sound: Off GPIB, Address 8
