GETTING STARTED
23
Power up
Step
1. Connect the power cord to
the rear panel socket. (No
need when using the
battery).
2. Turn On the main power
switch.
: On, : Off.
3. The ON/STBY indicator
on the front panel turns
red.
4. Press the ON/STBY key.
The indicator turns green
and the display becomes
active in 6 ~ 8 seconds.
5. The power icon on the
upper left corner of the
display shows the power
source. When both AC
mains and battery are
available, AC mains is
automatically selected.
AC mains
Battery
AC mains (battery
also installed)
Note
GDS-2000 recovers the state right before the power
OFF. The default setting can be recovered by
pressing the Save/Recall key → F1 (Default Setup).
For details, see page137.
To Next Page
