MEASUREMENT
57
FFR
Time between:
Source 1 first falling edge and
Source 2 first rising edge
FFF
Time between:
Source 1 first falling edge and
Source 2 first falling edge
LRR
Time between:
Source 1 first rising edge and
Source 2 last rising edge
LRF
Time between:
Source 1 first rising edge and
Source 2 last falling edge
LFR
Time between:
Source 1 first falling edge and
Source 2 last rising edge
LFF
Time between:
Source 1 first falling edge and
Source 2 last falling edge
Individual mode
Individual mode shows five selected measurement items, two
channels each, on the menu bar.
View
measurement
result
1. Press the Measure key.
Measure
2. The measurement results for two selected
channels appear on the menu bar, constantly
updated. Press F1 ~ F5 to change the
measurement item.
