GDS-2000 Series User Manual
130
USB
External flash drive, no practical
limitation on the amount of file.
When saved, the setup file is
placed in the root directory.
5. Press F4 (Save) to confirm
saving. When completed, a
message appears at the
bottom of the display.
Save
F 4
Note
The file will not be saved if the
power is turned Off or USB drive is
taken out before the message.
USB file utility
To edit USB flash drive
contents (create/ delete/
rename files and folders), press
F5. For details, see page123.
File
Utilities
F 5
Save waveform
Panel operation
1. (For saving to an external
USB flash drive) Connect
the drive to the front or rear
panel USB port.
Note: Only one host
connection, front or rear, is
allowed at a time.
Front
Rear
2. Press the Save/Recall key.
Save/Recall
3. Press F4 (Save Waveform).
The display shows the
available source and
destination options.
Save
Waveform
F 4
To Next Page
