SAVE/RECALL
131
4. Press F2 (Source). Use the
Variable knob to select the
source signal.
Source
F 2
CH1 ~ CH2
(2CH model)
Channel 1 ~ 2 signal
CH1 ~ CH4
(4CH model)
Channel 1 ~ 4 signal
Math
Math operation result
(page64)
RefA ~ D
Internally stored reference
waveforms A ~ D
5. Press F3 (Destination)
repeatedly to select the file
destination. Use the
Variable knob to select the
memory location or file
name.
Destination
USB
F 3
Memory
Internal memory, W1 ~ W20
