Page #169 background image
APPENDIX
169
Probe Specifications
Model-specific
GTP-060A Applicable to GDS-2062, GDS-2064
Bandwidth DC ~ 60MHz @ Position x 10
Rise time 5.8ns
GTP-150A Applicable to GDS-2102, GDS-2104
Bandwidth DC ~ 150MHz @ Position x 10
Rise time 2.3ns
GTP-250A Applicable to GDS-2202, GDS-2204
Bandwidth DC ~ 250MHz @ Position x 10
Rise time 1.4ns
Common
Position x 10 Attenuation Ratio 10:1
Input Resistance 10M when used with 1M input
oscilloscope
Input Capacitance 17pF approx.
Compensation
Range
10 ~ 35pF
Maximum Input
Voltage
500V CAT I, 300V CAT II (DC+Peak AC)
Derating with frequency
Position x 1 Attenuation Ratio 1:1
Bandwidth DC ~ 6MHz
Rise Time 58ns
Input Resistance 1M when used with 1M input
oscilloscope
Input Capacitance 47pF + oscilloscope capacitance
Compensation
Range
10 ~ 35pF
Maximum Input
Voltage
300V CAT I, 150V CAT II (DC+Peak AC)
Derating with frequency
Operating
Condition
Temperature –10°C ~ 55°C
Relative Humidity 85% @35°C
Safety Standard IEC 1010-1 CAT II
* Note: GW Instek reserves the right to change the probe model
type (GTP-060A, GTP-150A, GTP-250A) at anytime without notice
for probe types of similar specification.
