GDS-2000 Series User Manual
168
Auto Counter Resolution: 6 digits
Accuracy: ±2%
Signal source: All available trigger source
except the Video trigger
Control Panel
Function
Auto Set Automatically adjust Vertical Volt/div,
Horizontal Time/div, and Trigger level
Save Setup Internal memory: 20 sets
USB Flash drive: unlimited
Save Waveform Internal memory: 20 sets
USB Flash drive: unlimited
Save display
USB Flash drive: unlimited
Display LCD 5.6 inch, TFT, brightness adjustable
Resolution
(dots)
234 (Vertical) x 320 (Horizontal)
Graticule 8 x 10 divisions (menu On)
8 x 12 divisions (menu Off)
Interface
Go-No Go
Output
5V max/ 10mA TTL open collector
RS-232C DTE DB 9-pin male
GPIB (Optional) IEEE488.2 24-pin female
USB Host: Flash drive, Printer
Device: Remote control
2.0 full speed supported
Power Source Line Voltage 100V~240V AC, 48Hz~63Hz
Battery
(Optional)
Li-Ion pack, 11.1V average
8 hours charge time (Power On)
3 hours operating time (depend on
conditions)
Miscellaneous
Language
Selection
English, Traditional Chinese, Simplified
Chinese, others (depend on the region)
On-Line Help Available for most keys
Real-Time Clock Display: yy/mm/dd/hh/ss
(time stamp for saved data)
Operation
Environment
Ambient temperature 0 ~ 50°C
Relative humidity ≤ 80%, 40°C or below
≤ 45%, 41°C~50°C
Storage
Environment
Storage Temperature: -10°C~60°C, no condensation-
Relative humidity 93% @ 40°C
65% @ 41°C~60°C
Dimensions 254 (D) x 142 (H) x 310 (W) mm
Weight Approx. 4.3kg
