GETTING STARTED
11
GDS-2000 Series Overview
Series lineup
GDS-2000 series consists of 6 models, divided into 2-channel and 4-
channel versions.
Model name Frequency
bandwidth
Input
channels
Ext. trigger
input
Advanced
delay trigger
GDS-2062 60MHz 2 Yes Yes
GDS-2102 100MHz 2 Yes Yes
GDS-2202 200MHz 2 Yes Yes
GDS-2064 60MHz 4 No No
GDS-2104 100MHz 4 No No
GDS-2204 200MHz 4 No No
The differences between 2 and 4 channel model appearance are in
the horizontal key, trigger key, variable knob, and external trigger
input layout.
2-Channel model 4-Channel model
