GW Instek GDS-2000 Series - Page 124

GDS-2000 Series User Manual
124
4. Use the Variable knob to
move the cursor. Press F1
(Select) to go into the folder
or go back to the previous
directory level.
Select
F 1
Go back to the root directory
Go back to the previous
(higher) directory
Go into the folder
Create new folder
/ Rename file or
folder
1. Move the cursor to the file
or folder location and press
F2 (New Folder) or F3
(Rename). The file/folder
name and the character map
appear on the display.
Rename
F 3
New
Folder
F 2
2. Use the Variable knob to
move the pointer to the
characters. Press F1 (Enter
Character) to add a
character or F2 (Back Space)
to delete a character.
Enter
Character
F 1
Back
Space
F 2
