Auto test/Stop key
Auto test/Stop
→ See Program key (page32)
CH1 ~ 4 key
On/ Off
/ /
On/ Off
x1/ x10/ x100
CH1
Coupling
F 1
Invert
Off
F 2
BW Limit
Off
F 3
Probe
x1
F 4
Select coupling mode
F1
Turn waveform invert On/Off
F2
Turn bandwidth limit On/Off
F3
Select probe attenuation factor
F4
Cursor key
Cursor
(4CH) CH1/ 2/
3/ 4/ MATH
(2CH) CH1/ 2/
MATH
Source
CH1
F 1
Horizontal
F 2
Vertical
F 3
/
/
/
/
CURSOR
T
1
:-236.0us
T
2
: 160.0us
: 396.0us
f :2.525kHz
F 4
V
1
: 1.54V
V
2
:-460mV
: 2.00V
F 5
Select cursor source channel
F1
Select active horizontal cursor
F2
Select active vertical cursor
F3
