H3C S7500E Series Installation Manual

107
Dimensions
Card model Weight
Height Width Depth
LSQ1GP48EB0
3.25 kg (7.16
lb)
40 mm (1.57 in)
399 mm (15.71
in)
352 mm (13.86
in)
LSQ1TGX2EB0
2.93 kg (6.46
lb)
40 mm (1.57 in)
399 mm (15.71
in)
352 mm (13.86
in)
LSQ1TGX4EB0
2.93 kg (6.46
lb)
40 mm (1.57 in)
399 mm (15.71
in)
352 mm (13.86
in)
NOTE:
The dimensions of the cards of the S7500E series are expressed in H, W, and D. The followin
g
describes
them in detail:
• H—Height of the front panel of the card
• W—Width of the front panel of the card
• D—Depth from the front panel of the card to the connector.
Table 31 Power module weights and dimensions
Dimensions
Model Weight
Height Width Depth
PSR320-A 1.9 kg (4.19 lb)
40 mm (1.57 in) 140 mm (5.51 in) 350 mm (13.78 in)
PSR320-D 1.9 kg (4.19 lb)
40 mm (1.57 in) 140 mm (5.51 in) 350 mm (13.78 in)
PSR650-A 2.5 kg (5.51 lb)
40 mm (1.57 in) 140 mm (5.51 in) 350 mm (13.78 in)
PSR650-D 2.3 kg (5.07 lb)
40 mm (1.57 in) 140 mm (5.51 in) 350 mm (13.78 in)
PSR1400-A
8.3 kg (18.30
lb)
128 mm (5.04 in) 196 mm (7.72 in) 380 mm (14.96 in)
PSR1400-D
9.3 kg (20.50
lb)
128 mm (5.04 in) 196 mm (7.72 in) 380 mm (14.96 in)
PSR2800-ACV
9.9 kg (21.83
lb)
128 mm (5.04 in) 196 mm (7.72 in) 380 mm (14.96 in)
PSR6000-ACV
12.2 kg (26.90
lb)
128 mm (5.04 in) 196 mm (7.72 in) 380 mm (14.96 in)
Table 32 Fan tray weights and dimensions
Dimensions
Fan tray Weight
Height Width Depth
S7502E fan tray 0.9 kg (1.98 lb)
27 mm (1.06 in) 115 mm (4.53 in) 338 mm (13.31 in)
S7503E-S fan tray
0.9 kg (1.98 lb)
27 mm (1.06 in) 115 mm (4.53 in) 338 mm (13.31 in)
S7503E fan tray 1.6 kg (3.53 lb)
27 mm (1.06 in) 203 mm (7.99 in) 365 mm (14.37 in)
S7506E-S fan tray
2.2 kg (4.85 lb)
28 mm (1.10 in) 331 mm (13.03 in) 365 mm (14.37 in)
S7506E fan tray 2.2 kg (4.85 lb)
28 mm (1.10 in) 331 mm (13.03 in) 365 mm (14.37 in)
