109
PoE power consumption
The maximum PoE power consumption for the S7500E series depends on the type and number of PoE
cards, PoE power supply mode supported by each PoE card, and the number of ports that support PoE.
For example, if an S7503E switch has one LSQ1GV48SD0 (LSQM1GV48SD0), two LSQ1GV24PSC
(LSQM1GV24PSC0), and the SRPU does not support PoE, the maximum PoE power consumption of the
switch is 48 × 30 + 2 × 24 × 15.4 = 2179.2 W.
NOTE:
• The PoE power consumption is 0 if the switch does not supply PoE power.
• The maximum PoE power consumption refers to the sum of the power consumption of all PDs when all
ports supporting PoE are connected to PDs, and the maximum output power is reached.
• For more information about PoE power supply, see the chapter “Installing modules.”
Card power consumption
NOTE:
The model of a card is LSQM-prefixed on the card package and LSQ-prefixed on the card panel. For
example, LSQ1MPUA0 and LSQM1MPUA0 identify the same card. When you order a card, you refer to
the card by its LSQM-prefixed model. In this chapter, the card models are LSQ-prefixed, the same as
marked on the card panels.
Table 33 Card power consumption
Model
Minimum static power
consumption
Maximum dynamic power
consumption
LSQ1MPUA0 10 W 15 W
LSQ1CGP24TSC0 25 W 45 W
LSQ1CGV24PSC0 30 W 60 W
LSQ1MPUB0 (Salience VI-Lite) 40 W 45 W
LSQ1SRPA0 (Salience VI-Smart) 25 W 30 W
LSQ1SRPB0 (Salience VI) 42 W 50 W
LSQ1SRPD0 (Salience VI-Plus) 50 W 60 W
LSQ1SRP1CB0 (Salience VI-Turbo) 53 W 60 W
LSQ1SRP12GB0 (Salience VI-GE) 42 W 60 W
LSQ1SRP2XB0 (Salience VI-10GE) 55 W 65 W
LSQ1FP48SA0 34 W 85 W
LSQ2FP48SA0 30 W 75 W
LSQ2FT48SA0 24 W 30 W
LSQ1FV48SA0 30 W 35 W
LSQ1GP24TSA0 25 W 45 W
LSQ1GV24PSA0 30 W 60 W
