H3C S7500E Series Installation Manual

104
Appendix A Hardware specifications
Weights and dimensions
Table 29 Chassis weights and dimensions
Dimensions
Model Weight
Height Width Depth
S7502E < 15 kg (33.07 lb)
175 mm (6.89 in) (4
RU)
436 mm (17.17
in)
420 mm (16.54
in)
S7503E-S < 15 kg (33.07 lb)
175 mm (6.89 in) (4
RU)
436 mm (17.17
in)
420 mm (16.54
in)
S7503E < 30 kg (66.14 lb)
441 mm (17.36 in)
(10 RU)
436 mm (17.17
in)
420 mm (16.54
in)
S7506E-S < 40 kg (88.18 lb)
575 mm (22.64 in)
(13 RU)
436 mm (17.17
in)
420 mm (16.54
in)
S7506E < 40 kg (88.18 lb)
575 mm (22.64 in)
(13 RU)
436 mm (17.17
in)
420 mm (16.54
in)
S7510E < 45 kg (99.21 lb)
708 mm (27.87 in)
(16 RU)
436 mm (17.17
in)
420 mm (16.54
in)
S7506E-V < 50 kg (110.23 lb)
930 mm (36.61 in)
(21 RU)
436 mm (17.17
in)
420 mm (16.54
in)
NOTE:
• A rack unit (RU) is a measurement of the height of a rack. 1 RU is 44.45 mm (1.75 in).
• The model of a card is LSQM-prefixed on the card package and LSQ-prefixed on the card panel. For
example, LSQ1MPUA0 and LSQM1MPUA0 identify the same card. When you order a card, you refer
to the card by its LSQM-prefixed model. In this chapter, the card models are LSQ-prefixed, the same as
marked on the card panels.
Table 30 Card weights and dimensions
Dimensions
Card model Weight
Height Width Depth
LSQ1MPUA0
1.35 kg (2.98
lb)
45 mm (1.77 in)
199 mm (7.83
in)
352 mm (13.86
in)
LSQ1CGP24TSC0 2.8 kg (6.18 lb)
45 mm (1.77 in)
399 mm (15.71
in)
352 mm (13.86
in)
LSQ1CGV24PSC0
2.86 kg (6.31
lb)
45 mm (1.77 in)
399 mm (15.71
in)
352 mm (13.86
in)
LSQ1MPUB0 (Salience VI-Lite) 3.6 kg (7.94 lb)
45 mm (1.77 in)
399 mm (15.71
in)
352 mm (13.86
in)
