114
External interfaces
SRPU model
Console
port
Management
Ethernet port
(10/100BASE-TX)
CF card
interface
Other interfaces
LSQ1SRP2XB0
(Salience VI-10GE)
One One One
2 × 10-Gigabit XFP interfaces
(LC)
NOTE:
A combo port is a logical port that comprises an SFP interface and an RJ-45 Ethernet interface. Only
one of them can be active at a time, and the other is inactive. By default, the interface with a smaller
number is active.
To use an inactive interface of the combo port, use the undo shutdown command to activate the
interface. When the interface is activated, the previous active interface of the combo port is
automatically shut down and becomes inactive.
SRPU ordering guide
Table 38 shows the models and number of SRPUs that an S7500E chassis supports.
NOTE:
The S7500E series except the S7503E-S supports two SRPUs, which must be of the same model.
In Table 38, “z” in
di
cates compatible, and “—” indicates incompatible.
The model of a card is LSQM-prefixed on the card package and LSQ-prefixed on the card panel. For
example, LSQ1MPUA0 and LSQM1MPUA0
identify the same card. When you order a card, you refer
to the card by its LSQM-prefixed model. In this chapter, the card models are LSQ-prefixed, the same as
marked on the card panels.
Table 38 SRPU ordering guide
Applicable chassis
(right)
SRPU model
(below)
S7502E
S7503E-
S
S7503E
S7506E-
S
S7506E S7510E
S7506E-
V
LSQ1MPUA0
z
— — — — — —
LSQ1CGP24TSC0 —
z
— — — — —
LSQ1CGV24PSC0 —
z
— — — — —
LSQ1MPUB0
(Salience VI-Lite)
— —
z
z
z
z
LSQ1SRPA0
(Salience VI-Smart)
— — —
z
— — —
LSQ1SRPB0
(Salience VI)
— —
z
z
z
z
LSQ1SRPD0
(Salience VI-Plus)
— —
z
z
z
z
